WABCO 4006120000 Enhanced Easy-Stop Trailer ABS Valve/ECU Kit, 2S/1M Part Number: 815-4006120000

Not Yet Rated | Write the First Review

The WABCO 4006120000 is an Enhanced Easy-Stop trailer ABS valve/ECU kit for single-axle 2S/1M systems. The kit centers on the 4005001010 integrated unit, which combines an air brake relay valve with a solenoid modulator and a metal bracket-mounted ABS ECU. The included 8946073120 power adapter cable allows direct retrofit from the original Easy-Stop system without rewiring the trailer harness. Designed as a retrofit for original Easy-Stop valve/ECU 4725000210. Replaces obsolete Meritor part number R955344.

Product Description

Manufacturer: WABCO

Part Number: 4006120000

Type: TCS II Basic

Function: Enhanced Easy-Stop Trailer ABS Valve/ECU Kit

System: 2S/1M (2 wheel speed sensors, 1 modulating valve)

Voltage: 12V

Max. Operating Pressure: 188.5 psi

Port Thread 1: 2x 3/4"-14 Dry Seal NPTF

Port Thread 2: 4x 3/8"-18 Dry Seal NPTF

Port Thread 3: Flap Exhaust

Port Thread 4: 3/8"-18 Dry Seal NPTF

Ingress Protection: IP66

Operating Temperature: -40°C to +65°C

Kit Includes: 4005001010 Valve/ECU Unit, 8946073120 Power Adapter Cable, Instructions

Retrofit For: WABCO 4725000210 (original Easy-Stop)

Replaces: Meritor R955344

Cross References: 400 612 000 0, 4006120000, 815-4006120000, 650-R955344, 4721950330, 472 195 033 0, 4725000210, 400 500 101 0, R955344, TDA R955344, TDAR955344, GEN2-0210, GEN20210, MERR955344, 8235-R955344, 4725000210, S472 500 021 0, TWDR955344, RWR955344
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.

Meritor WABCO R955344 Installation Guide (.pdf)
