Pro LED SLP1018 Stellar Vision 18" Amber LED Warning Light Bar, 19 Flash Patterns, 12/24V Part Number: 689-SLP1018

Not Yet Rated | Write the First Review

The Pro LED SLP1018 Stellar Vision is a Class 1 18" low-profile amber LED warning light bar featuring COB (Chip on Board) LEDs with a V-cut optical design and 360-degree Nova optics for maximum light dispersion. The elongated octagonal aluminum housing stands just 1" tall without mounting hardware. Two mounting options using four threaded holes on the bottom: bolt-on brackets that span the width of the light at each end, or threaded studs for direct mounting. Stainless steel hardware included. 16'6" 3-wire power cable. Salt spray and vibration tested. IP67 rated. Note: momentary switch for pattern selection not included. Multi-volt 12V/24V.

Product Description

Manufacturer: Pro LED

Part Number: SLP1018

Classification: SAE J845 Class 1

Function: Warning Light Bar

LED Technology: COB (Chip on Board)

LED Color: Amber

Lens Color: Clear

Lens Material: Polycarbonate

Housing Material: Aluminum

Optics: V-Cut, 360-Degree Nova

Wattage: 100W

Flash Patterns: 19 Selectable

Mounting: Bolt-On Brackets or Stud Mount

Length: 18"

Width: 8"

Height: 1" (without brackets), 2-5/8" (with brackets)

Cable Length: 16'6"

Water/Dust Resistance: IP67

Salt Spray Tested: Yes

Vibration Tested: Yes

Includes: Stainless Steel Mounting Hardware

Note: Momentary switch for pattern selection not included

Voltage: Multi-Volt 12V/24V

Regulatory Compliance: SAE J845 Class 1, SAE J578, ECE R65 Class 2, ECE R10, ICAO Type C

Flash Patterns

1. Single Flash All Lights — SAE Class 1, California Title 13

2. Double Flash All Lights — SAE Class 1

3. Quad Flash All Lights — SAE Class 1

4. Quint Flash All Lights — SAE Class 1

5. Single Flash, All By Day — ECE R65 Class 2

6. Single Flash, All By Night — ECE R65 Class 1

7. Single Flash, Left/Right Alternate

8. Quad Flash, Left/Right Alternate

9. Single Flash, Outside In Alternate

10. Quad Flash, Outside In Alternate

11. Rotation, Slow Mode

12. Rotation, Fast Mode

13. Single, Odd/Even

14. Patrol Mode, Left to Right Then Right to Left

15. Arrow Flash, Left to Right

16. Arrow Flash, Right to Left

17. Airport Mode, Single Flash — ICAO Type C

18. Airport Mode, Single Flash — ICAO Type D

19. Steady On

Cross References: 689-SLP1018, SLP1018
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
