Pro LED 8712Y Double-Face Pedestal Fender Turn Signal Lamp, LH/RH, Dual Stud Mount, Clear Lens, 12V Part Number: 689-8712Y

Not Yet Rated | Write the First Review

The Pro LED 8712Y is a double-face pedestal LED turn signal lamp for fender-mount applications on older trucks with rounded front fenders. Both faces feature amber LEDs behind a clear lens and flash simultaneously as a turn signal, making this light universal for either left or right side installation. With the vehicle lights on, both faces illuminate as running lights via the third wire of the 3-wire pigtail. An amber side marker light is integrated into the housing. Each face features 21 LEDs. Mounts via two studs spaced 2-1/16" center to center. DOT compliant. 12V.

Product Description

Manufacturer: Pro LED

Part Number: 8712Y

Function: Double-Face Fender Turn Signal/Running Light

Side: LH or RH

Front Face: Amber LEDs, Clear Lens — Turn Signal/Running Light

Rear Face: Amber LEDs, Clear Lens — Turn Signal/Running Light

Side Marker: Amber

Diode Count: 21 per face

Lens Color: Clear

Mounting: Dual Studs, 2-1/16" Centers

Termination: 3-Wire Pigtail

Voltage: 12V

Regulatory Compliance: DOT

Cross References: 8712Y, 689-8712Y, 808-38712, 38712, 710270387120
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.

We've been selling Pro LED lights and accessories since 2006, and they're always innovating and coming up with new products. We're sharing a copy of the latest Warning Light Products brochure from Pro LED and all of the products are available with the same great service you rely on from AnythingTruck.com.

Pro LED Warning Lights and Accessories Brochure (.pdf)
