Pro LED 5530LH Double-Face Pedestal Fender Turn Signal Lamp, LH, Dual Stud Mount, Side Marker, 12V Part Number: 689-5530LH

Not Yet Rated | Write the First Review

The Pro LED 5530LH is a left-hand double-face pedestal LED turn signal lamp for fender-mount applications on older trucks with rounded front fenders. Both faces flash simultaneously as a turn signal — the amber face points forward and the red face points rearward. With the vehicle lights on, both faces illuminate as running lights via the third wire of the 3-wire pigtail. A 2-LED side marker light indicates the LH side clearance position. Each face features 25 LEDs. Mounts via two studs spaced 2" center to center. DOT compliant. 12V.

Product Description

Manufacturer: Pro LED

Part Number: 5530LH

Function: Double-Face Fender Turn Signal/Running Light

Side: LH

Front Face: Amber — Turn Signal/Running Light

Rear Face: Red — Turn Signal/Running Light

Side Marker: Amber, 2 LEDs

Diode Count: 25 per face

Face Size: 4.67" Square

Mounting: Dual Studs, 2" Centers

Termination: 3-Wire Pigtail

Voltage: 12V

Regulatory Compliance: DOT

Cross References: 5530LH, 689-5530LH, 580-G5530, G5530, GRTG5530, 7376-G5530, M42332R/Y, M42332RY, GROG5530, ZBJDG5530, 2753S1G, 2758S1G, 2759S1G, LL021509, LL021609, 2753, 27533, 2759, 571.LD25AR52L, 571LD25AR52L, 571.LD25AR521L, 38756, CPL68L, G5530-5, G55305
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.

We've been selling Pro LED lights and accessories since 2006, and they're always innovating and coming up with new products. We're sharing a copy of the latest Warning Light Products brochure from Pro LED and all of the products are available with the same great service you rely on from AnythingTruck.com.

Pro LED Warning Lights and Accessories Brochure (.pdf)
