Pro LED 312AC Class 1 Double-Row 12-LED Amber/White Warning Light, 19 Patterns, Surface Mnt, 12/24V Part Number: 689-312AC

Not Yet Rated | Write the First Review

The Pro LED 312AC is a Class 1 double-row amber and white LED warning light with 12 SMD LEDs arranged in one row of amber and one row of white, with 19 selectable flash patterns. Clear polycarbonate lens in an aluminum base. Supports synchronized and alternating flash configurations via 4-wire pigtail. Two-screw surface mount with 4-1/8" mounting centers. Foam gasket and mounting hardware included. Note: momentary switch for pattern selection not included. SAE J845 Class 1 certified. Multi-volt 12V/24V.

Product Description

Manufacturer: Pro LED

Part Number: 312AC

Classification: SAE J845 Class 1

Function: Warning Light

LED Technology: SMD

LED Colors: 1 Row Amber, 1 Row White

Diode Count: 12

Configuration: Double Row

Lens Color: Clear

Lens Material: Polycarbonate

Base Material: Aluminum

Flash Patterns: 19 Selectable

Multi-Light Sync: Yes

Multi-Light Alternate: Yes

Termination: 4-Wire Pigtail, 7-1/2"

Mounting: 2-Screw Surface Mount

Mounting Centers: 4-1/8"

Length: 4-1/2"

Width: 1-11/16"

Height: 1/2" (with gasket)

Current Draw: 1.0A @ 12V, 0.5A @ 24V

Includes: Foam Gasket, Mounting Hardware

Note: Momentary switch for pattern selection not included

Voltage: Multi-Volt 12V/24V

Cross References: 689-312AC, 312AC
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.

We've been selling Pro LED lights and accessories since 2006, and they're always innovating and coming up with new products. We're sharing a copy of the latest Warning Light Products brochure from Pro LED and all of the products are available with the same great service you rely on from AnythingTruck.com.

Pro LED Warning Lights and Accessories Brochure (.pdf)
