Meritor R803102 Automatic Slack Adjuster. Type 3, 1-1/4" 24 Spline, 5-1/2" Long Part Number: 650-R803102

Not Yet Rated | Write the First Review

Special Notes

none

Product Description

Manufacturer: Meritor

Part Number: R803102

Type 3 Automatic Slack Adjuster

Stroke Sensing Adjuster - Adjusts brake automatically based on drum brake pushrod stroke length

Fits 1-1/4" - 24 spline camshaft

5-1/2" Arm Length (Span)

Straight slack adjuster, No offset

Uses red piston

For use on drum brakes with a type 16 or type 20 brake chamber

Includes one slack adjuster without clevis, installation instructions, and an installation template

Meritor's unique automatic slack adjuster design keeps brake in constant adjustment; eliminates the need for frequent under-the-truck brake adjustments; reduces brake maintenance costs; reduces vehicle safety inspection citations; and allows for optimum brake performance.

Cross References: A113275H1152, AS1038, AS1138, CS56038, A253275N768S, A353275N768, TDAR801003, RWR801003, R801003
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
