MGM 3230651 TR3030LP3 Long Stroke Spring Brake with 18" Threaded Push Rod, 3" Stroke, 3/4" Push Rod

Part Number:460-3230651
Not Yet Rated | Write the First Review
$184.79 USD
MGM 3230651 TR3030LP3 Long Stroke Spring Brake with 18" Threaded Push Rod, 3" Stroke, 3/4" Push Rod
Processing...
Availability
Qty in Stock: 5
Quantity in Stock reflects available inventory as of 5:00 AM CST.

Product Details


Special Notes
none
Product Description
Manufacturer: MGM Brake
Part Number: 3230651
Complete long stroke service and spring brake assembly
Type 30 spring brake chamber
Type 30 service brake chamber
Stroke: 3.0" (Long)
Includes spring cage bolt
Spring chamber permanently attached for safety
Epoxy-coated internal parts for long life
Used in transit, Hendrickson Intraax and Vantraax applications
MGM Spring Brake Schematic
Combination Spring Brake Specifications
A: 9.99" (Length of chamber from face of stud housing to the end of the spring housing)
B: 7.61" (Length of Piggyback center body to end of spring housing)
C: 8.32"
D: 8.21" (Dimension at rolled seal)
E: 4.75" (Stud Spacing)
F: 5/8"-11 UNC (Stud Size)
G: 3/4"-16 UNF (Push rod size)
X: 18.0" (Push rod length)

Cross References: 3230651, 460-3230651, MGM 3230651, MGM3230651, 5554-3230651
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
