Spring Pro 881190 Air Bag, Replaces Goodyear 1R12-523 Air Bag & Navistar 3541732C1 Part Number: 280-1190

Not Yet Rated | Write the First Review

Top	Bottom

Special Notes

No dimples on the top plate

Product Description

Manufacturer: Spring Pro

Part Number: 881190

Minimum Length: 5.90"

Maximum Length: 23.79"

Bottom Stud: M12 x 1.75

Bottom Stud Length: 2.00"

Bellows Diameter: 10.00"

Includes angle bracket

Goodyear Bellows Number: 566-24-3-066

Goodyear Part Number: 1R12-523

Firestone Bellows Number: 1T15XR-9

Firestone Part Number: W01-358-1190

Replaces: Navistar 3541732C1

Cross References: 1190, 280-1190, 881190, W013581190, 1T15XR9, 566243066, S-23938, S23938, 1R12523
A cross reference listing means that this air bag may be a suitable replacement for the part numbers listed. Please double check the dimensions and location of mounting holes and stud to be sure the air bag will work in your application.
