Dayton Parts TRA-086 Heavy Duty Fruehauf Trailer Z Spring Part Number: 150-TRA086

Not Yet Rated | Write the First Review

Special Notes

This spring is a suitable replacement for TRA-082 which is no longer available. The TRA-086 must be replaced in pairs when switching over from the TRA-082.

Product Description

Manufacturer: Dayton Parts

Part Number: TRA-086

Fruehauf Trailer Z Spring

Width: 3"

(A) PL-1 Front: 21-7/8"

(B) PL-1 Rear: 21-1/16"

(C) Arch Front: 5"

(D) Pack Thickness: 1-3/4"

(E) Arch Rear: 9-1/8"

No. of Leaves: 1

Grading: 1/1.750, Full Taper

Capacity: 21,000 lbs. Per Axle

Applications: Fruehauf NT-2/NT-2W Pro Trac Single/Tandem Axle Trailer Air Suspension

Cross References: TRA-086, TRA086, 150-TRA086, HSTRA-086, UVA000092-001, UVA000092001, TRA-082, TRA082, UCF008314-001, UCF008314001
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
