Genuine WABCO 4725002230 ABS/ATC Valve Package, 5.5 PSI Crack Pressure, 4S/4M, 6S/6M Part Number: 815-4725002230

Not Yet Rated | Write the First Review

Special Notes

none

Product Description

Manufacturer: WABCO

Part Number 472 500 223 0

472 500 223 0 ABS Relay Valve/Modulator Valve/ATC Valve Assembly

Crack Pressure: 5.5 PSI

Voltage: 12-Volts DC

ABS Configuration: 4S/4M, 6S/6M; Bayonet-Style Connector

Provides an alternative to separate valve installation by combining a service brake relay valve with two ABS modulator valves and one ATC valve. For D- and E-Version ECUs only.

Includes: 973 011 026 0 relay valve, 472 195 079 0 modulator valve, 472 195 078 0 modulator valve, and 472 170 797 0 ATC Valve,

This valve assembly is available as a kit with adapter cables under part number R950135

Cross References: 472 500 223 0, 815-4725002230, R950135, S4725002230, 4725002230, 9730110260, 4721950790, 4721950780, S8946011322, 8946011322, S8946011362, 8946011362
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
