PTP PR1308Q Air Brake Shoes & Hardware Kit for Meritor 15" x 4" 'Q' Quick Change Part Number: 620-PR1308Q

Not Yet Rated | Write the First Review

Product Description

Fits 15" diameter × 4" wide Meritor “Q” quick‑change front brakes

Shoe FMSI Number: 1308T

New brake shoes (no core charge)

Includes two air brake shoes and one hardware kit

Premium 23,000 lb brake lining

Brake Lining Certifications by Greening Testing Laboratories Regarding SAE J2115 Section 6 FMVSS 121 Dynamometer Test

Brake Retardation: Meets requirements, minimum pass margin approximately 2.4%

Brake Power: Meets requirements, maximum pressure = 75.5 lbf/in² (9 +0, –1 ft/s² deceleration < 100 lbf/in²)

Recovery: Meets requirements, maximum pressure = 79.5 lbf/in² (12 ± 0.5 ft/s² deceleration < 85 lbf/in² and > 20 lbf/in²)

Testing conducted in accordance with FMVSS 121 criteria @ 23,000 lb axle load, 16-1/2" × 7" S‑cam air brake, 30/30LS chamber × 5.5" span input power (slack adjuster), and a 19.6" tire rolling radius

Cross References: PR1308Q, 620-PR1308Q, HD1308Q, HD1308QKIT, A3222F1982, M3191, 1308Q, L2929, 385528, KSMA2121308Q, 650-KSMA2121308Q, TDAKSMA2121308Q, 8235-KSMA2121308Q, L1308Q-RF3, L1308QRF3, 3099317
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
