MGM 3429051 Type 2430 Spring Brake Assembly, 2.5" Stroke

Product Details

Special Notes

none

Product Description

Manufacturer: MGM Brake

Part Number: 3429051

Complete service and spring brake assembly

Type 30 spring brake chamber

Type 24 service brake chamber

Stroke: 2.5" (Standard)

Includes spring cage bolt

Spring chamber permanently attached for safety

Combination Spring Brake Specifications

A: 9.04" (Length of chamber from face of stud housing to the end of the spring housing)

B: 6.91" (Length of Piggyback center body to end of spring housing)

C: 7.38"

D: 8.21" (Dimension at rolled seal)

E: 4.75" (Stud Spacing)

F: 5/8"-11 UNC (Stud Size)

G: 5/8"-18 UNF (Push rod size)

X: 8.0" (Push rod length)

Cross References: 3429051, 460-3429051, ABPN42142430CD, EGC-2430-LS, EGC2430LS, MGM3429051, GC2430, 5554-3429051, 3429080, 3429081, 3430376, 1694056C91, OTR2430SB, 2430SB, F8HS2225LA, 3919096, GC2430MD, 0765578, 0765586, 1171024, 94722430, D3TJ2225CB, D7HT2225EA, E4HS2225BA, E5HT2225AA, E6HT2225FA, E7HS2225CA, E8HT2225BA, 6814201018, HDXGC2430, TKG0697-8, Y-KH0529-4, 15509181, 15509182, 15509524, 15556881, 15556882, 15558009, 15558010, 15586708, 15605720, 15605721, 15605721, 15605722, 15605724, 15605725, 15605726, 15605727, 16505723, 2098827, 2098831, 799384, 799710, 799711, 799785, 799786, 1392430004, 160335, 160567, 160787, 160794, 160795, 160840, 160849, 160850, 160886, 160889, 160887, 160888, 160971, 160972, 161035, 161057, 161173, 161196, 161263, 161427, 161475, 161477, 162078, 162112, 162330, 162344, 162360, 162425, 162438, 162459, 162466, 162502, 162503, 162529, 162539, 162551, 162554 162609, 162612, 162664, 162673, 162682, 162683, 162725, 162740, 162758, 162816, 162817, 162822, 162823, 162827, 162873, 162950, 162962, 162977, 162978, 163000, B2430GC, 08-09-2430, 104946-01, 104946-02, 104946-03, 19QE453RP19, 19QE39304R, 19QE39304RP2, 19QE39305RP1, 19QE39305RP2, 19QE453RP10, 19QE453RP11, 19QE453RP17, 19QE453RP18, 19QE453RP20, 19QE453RP8, 19QE81000R, 5396-GC2430, J-3276-X-24, J1-3276-X-24, J10-3276-X-24, 03-05805, 03-05806, 03-07383-001, 03-07384-001, 03-07384-002, 03-4226, 03-4227, 03-7383-002, 78102-0013, 78102-0049, 78102-0115, 78102-0116, 78102-0117, 85108327
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. Please double check the description to be sure it will work in your application.
