- Product Description
- Manufacturer: PTP
- Part Number: 9441
- This brake drum is used on Dexter Axle 9K & 10k 12.25" x 3.375" brakes.
- Brake Diameter: 12-1/4"
- Brake Width: 3-3/8"
- Holes: 8
- Bolt Circle: 7-1/2"
- Replaces Dexter#: 009-044-01
This drum was used through July of 2009.
Axles built by Dexter after July had a
closer bearing spacing, and Dexter went
to a one-piece hub & drum combination
that was not compatible with the previous design.
In May of 2013, Dexter discontiued that new
one-piece hub & drum combination and went to
a two-piece design with the same bearing spacing.
This drum is not compatible with that new drum that
came out in 2013.
Cross References: 9441, 9441M, 009-044-01
