Haldex AL364041 Trailer ABS Relay Valve, Reservoir Mount, 6-Port, 4 PSI, 12V Part Number: 070-AL364041

Not Yet Rated | Write the First Review

The Haldex AL364041 is a reservoir mount trailer ABS relay valve with six delivery ports, 4 psi crack pressure, 12V. The valve mounts directly to the air reservoir via a pipe nipple in the 1/2" NPT supply port. This is a bare valve and modulator assembly; the ECU and mounting bracket must be transferred from the existing valve during installation.

Special Notes

ECU and bracket must be transferred from existing valve during installation.

Product Description

Manufacturer: Haldex

Part Number: AL364041

OEM Part Number: 364141112

Function: Trailer ABS Relay Valve and Modulator Assembly

Mounting: Reservoir Mount (pipe nipple in supply port)

Voltage: 12V

Crack Pressure: 4 psi

Supply Port: 1/2" NPT (x1, reservoir mount)

Delivery Ports: 3/8" NPT (x6)

Control Port: 3/8" NPT

Cross References: AL364041, 070-AL364041, 364141112, 400180AA, 400212K, 401180AB, 767653082868, AL364041-MD, HDX AL364041, HDXAL364041, 364141112RP, 5396-AL364041, MIDAL364041, MBIAL364041, ZZAL364041, MAL364041
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
