Bendix OR284358X High Temperature D-2 Air Compressor Governor, 105-125 PSI, Reman Part Number: 061-OR284358X

4

| Write a Review

Ratings Snapshot

5.0

out of 5

5 (4)

4 (0)

3 (0)

2 (0)

1 (0)

Would recommend this product.

100%

Special Notes

none

Product Description

Manufacturer: Bendix

Part Number: OR284358X

Condition: Remanufactured

Pressure Range: 105-125 psi (Adjustable)

High temperature o-rings and waterproof cover

Includes gasket and pipe plugs

The Bendix D-2 governor controls the pressure in the air system. The compressor runs continuously while the engine is running, so the D-2 governor activates the compressor's unloader mechanism when system pressure reaches the governor's cut-out pressure. It deactivates the unloaders once system pressure has dropped to the governor's cut-in pressure. While unloaded, the compressor simply pumps air from one cylinder to the other rather than send it to the tank.

Cross References: 284358N, 284358, 284358X, OR284358X, 284358R, 102178, 102178X, 108818, 227435, 275491, 275491X, 275707, 275707X, 18537, KN18500X, KN18530, KN18537, VHD18537
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
