Bendix K033214 SR-2 Spring Brake Valve, Replaces Obsolete PN 287376

Product Details

Special Notes

none

Product Description

Manufacturer: Bendix

Part Number: K033214

Condition: New

SR-2 Spring Brake Valve

Reservoir Nipple: 3/4" NPT

Does NOT have trailer service port for anti-compounding

Spring Brake Reservoir Supply Port: 3/4" NPT (without Check Valve)

Trailer Supply Port: 1/4" NPT

Service Reservoir Port 1: 1/4" NPT

Service Reservoir Port 2: 1/4" NPT

Delivery Ports: 3/8" NPT

Brake Charging Priority: Service Brake Priority

Opening Pressure: 65 PSI

Anti-Compounding: No

The SR-2 and SR-4 spring brake valves are designed for use in trailer air brake system. The SR-2 differs from the SR-4 in that it uses a dedicated spring brake reservoir for release of the trailer spring brakes while the SR-4 utilizes the service reservoirs for this purpose. Mounted on one of the trailer reservoirs, these valves control both the parking and the emergency brake functions of the spring brakes and using integral pressure protection and check valves they isolate reservoir failures preventing automatic application of the trailer spring brakes. An integral anti-compound feature is part of both valves.

Cross References: K033214, 060-K033214, K033047, GN287376, 322-GN287376, 287376, 287376R, 288497, 287375, BKA287, 1970061021, 9010888, 1191847, 111707, 12361, KN26000, 6300287375, 401183, 51301, 51321, EBN287376X, 270-EBN287376X, EBN287376N, 270-EBN287376N, R955287376, 650-R955287376, R955287376N, 650-R955287376N, 287376RX, 070-287376RX
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
