Bendix K035691 MV‑3 Dash Valve, 3/8" PTC Ports, 0.315" Unthreaded Mounting Holes, No Buttons Part Number: 060-K035691

Not Yet Rated | Write the First Review

This MV‑3 variant (Bendix K035691) features 3/8" push‑to‑connect supply, delivery, and exhaust ports along with 0.315" unthreaded mounting holes. It is supplied without buttons and uses the standard MV‑3 port configuration.

Special Notes

none

Product Description

Manufacturer: Bendix

Part Number: K035691

Condition: New

Supply 11 Port: 3/8" PTC

Supply 12 Port: 3/8" PTC

Delivery 21 Port: 3/8" PTC

Delivery 22 Port: 3/8" PTC

Exhaust Port: 3/8" PTC

Auxiliary Port: None

Mounting Holes: Ø0.315" unthreaded (4x)

Tractor Trip Pressure: 30 ± 10 PSI

Trailer Trip Pressure: 35 ± 10 PSI

Trailer Override Pressure: 25 ± 5 PSI

Button(s) Included: No

The Bendix® MV‑3® Dash Control Module is a dual‑button, push‑pull valve used to control the tractor and trailer parking brake circuits from a single dash‑mounted unit. According to Bendix, it "duplicates the functions of any existing two‑ or three‑valve push‑pull system and has the advantages of reduced plumbing."

The MV‑3 combines tractor protection, trailer supply, and system park functions into one compact assembly, using a dual‑circuit supply check valve to manage both primary and secondary reservoirs. All air connections are located at the rear of the valve body, with an optional auxiliary port available on certain models.

Cross References: K035691, 060-K035691, BW K035691, BWK035691, 745-K035691, BANK035691, BXK035691, 21315044, 21750583, K034652, K034654, K062016 060-KO35691, KO35691
A cross reference listing means that this item should be a suitable replacement for the part numbers listed. You should check the description to be sure it will work in your application.
