Replacement Electric
Trailer Brake Assemblies
These are complete electric brake assemblies for replacement of your Dexter trailer brakes. The brake shoes and hardware are pre-assembled onto a new backing plate, so all you have to do is cut the electric wires near your current backing plate, unbolt and remove the backing plate, and bolt up the new backing plate and attach the included brake's wires. It's that simple.
Right-Hand, Left-Hand, Which do I need? It is a simple task to determine whether you need a left or right-hand brake assembly. Look at your existing electric trailer brake assembly with the magnet at the bottom. The electric brake actuating arm with the magnet attached is connected to a hinge pin near the top of the backing plate. The actuating arm is going to curve around to the left or right. If it curves to the right, you need a right-hand electric brake assembly. If it curves left, you need a left-hand brake assembly.
10" x 2-1/4" Electric Brake Assemblies
with 4 Bolt Backing Plate for Dexter Axles
These are replacement brake assemblies for 3,500 pound Dexter trailer axles with 10" x 2.25" electric brakes.
| Part Number |
Notes | Price | ||
|---|---|---|---|---|
 |
2326 | 10" x 2.25" LH Electric Brake Assembly with 4 Bolt Backing Plate for Dexter Axles | On Sale! $35.99 You save $24.03! |
|
 |
2327 | 10" x 2.25" RH Electric Brake Assembly with 4 Bolt Backing Plate for Dexter Axles | On Sale! $35.99 You save $24.03! |
12" x 2" Electric Brake Assemblies
with 5 Bolt Backing Plate for Dexter Axles
These are replacement brake assemblies for Dexter trailer axles up to 6,000 pounds with 12" x 2" electric brakes.
| Part Number |
Notes | Price | ||
|---|---|---|---|---|
 |
23105 | 12" x 2" LH Electric Brake Assembly with 5 Bolt Backing Plate for Dexter Axles | On Sale! $43.99 You save $23.50! |
|
 |
23106 | 12" x 2" RH Electric Brake Assembly with 5 Bolt Backing Plate for Dexter Axles | On Sale! $43.99 You save $23.50! |
12" x 2" Electric Brake Assemblies
with 4 Bolt Backing Plate for Dexter Axles
These are replacement brake assemblies for Dexter trailer axles up to 6,000 pounds with 12" x 2" electric brakes. Note that these brake assemblies are drilled to fit Dexter's 4 and 5 bolt mounting patterns.
| Part Number |
Notes | Price | ||
|---|---|---|---|---|
 |
231059 | 12" x 2" LH Electric Brake Assembly with 4 Hole and 5 Hole Mounting Patterns for Dexter Axles | $64.95 | |
 |
231069 | 12" x 2" RH Electric Brake Assembly with 4 Hole and 5 Hole Mounting Patterns for Dexter Axles | $64.95 |
12-1/4" x 2-1/2" Electric Brake Assemblies
with 4 Bolt Cast Backing Plate for Dexter Axles
These are replacement brake assemblies for Dexter 7.2K trailer axles with 12.25" x 2.50" electric brakes. These brake assemblies have the cast backing plate with 4 mounting holes.
| Part Number |
Notes | Price | ||
|---|---|---|---|---|
 |
23428 | 12-1/4" x 2-1/2" 7.2K LH Electric Brake Assy with 4 Bolt Backing Plate for Dexter Axles | $169.55 | |
 |
23429 | 12-1/4" x 2-1/2" 7.2K RH Electric Brake Assy with 4 Bolt Backing Plate for Dexter Axles | $169.55 |
12-1/4" x 3-3/8" Electric Brake Assemblies
with 4 Bolt Cast Backing Plate for Dexter Axles
These are replacement brake assemblies for Dexter 8K trailer axles with 12.25" x 3.375" electric brakes. These brake assemblies have the cast backing plate with 4 mounting holes and auto adjusting brakes.
| Part Number |
Notes | Price | ||
|---|---|---|---|---|
 |
23434 | 12-1/4" x 3-3/8" 8K FSA LH Electric Brake Assy with 4 Bolt Backing Plate for Dexter Axles | $164.95 | |
 |
23435 | 12-1/4" x 3-3/8" 8K FSA RH Electric Brake Assy with 4 Bolt Backing Plate for Dexter Axles | $164.95 |
12-1/4" x 3-3/8" Electric Brake Assemblies
with 5 Bolt Cast Backing Plate for Imported Axles
These are replacement brake assemblies for imported trailer axles with 12.25" x 3.375" electric brakes. This electric brake assembly is NOT used on Dexter or Kelsey Hayes axles. Note that it has a 5-bolt mount. Dexter doesn't use a 5-bolt mount. Hayes uses a 5-bolt mount, but their brake shoes are 3.5" wide.
These brakes are found on trailers with imported axles and are hard to find. So far, we know trailers made by Quality Trailer, H and H Trailer, J and J Trailer, and Lippert Trailer have been found to use this brake assembly. We're sure there are others and will add them as we find out.
| Part Number |
Notes | Price | ||
|---|---|---|---|---|
 |
4738L | 12-1/4" x 3-3/8" LH Electric Brake Assy with 5 Mounting Hole Cast Backing Plate (Doesn't Fit Dexter) | $208.38 | |
 |
4738R | 12-1/4" x 3-3/8" RH Electric Brake Assy with 5 Mounting Hole Cast Backing Plate (Doesn't Fit Dexter) | $208.38 |
12-1/4" x 3-3/8" Electric Brake Assemblies
with 7 Bolt Cast Backing Plate for Dexter Axles
These are replacement brake assemblies for Dexter 9K-10K trailer axles with 12.25" x 3.375" electric brakes. These brake assemblies have the cast backing plate with 7 mounting holes and auto adjusting brakes.
| Part Number |
Notes | Price | ||
|---|---|---|---|---|
 |
23450 | 12-1/4" x 3-3/8" 9K-10K FSA LH Electric Brake Assy with 7 Bolt Backing Plate for Dexter Axles | $144.95 | |
 |
23451 | 12-1/4" x 3-3/8" 9K-10K FSA RH Electric Brake Assy with 7 Bolt Backing Plate for Dexter Axles | $144.95 |
12-1/4" x 3-1/2" Electric Brake Assemblies
with 5 Bolt Cast Backing Plate for Hayes Axles
These are replacement brake assemblies for Hayes trailer axles with 12.25" x 3.50" electric brakes. These brake assemblies have the cast backing plate with 5 mounting holes and auto adjusting brakes. These brake assemblies are NOT used on Dexter trailer axles.
| Part Number |
Notes | Price | ||
|---|---|---|---|---|
 |
K568255.1 | 12-1/4" x 3-1/2" RH Electric Brake Assy with 5 Mounting Stud Cast Backing Plat - Replaces AL-KO | $291.09 | |
 |
K568255.2 | 12-1/4" x 3-1/2" LH Electric Brake Assy with 5 Mounting Stud Cast Backing Plate - Replaces AL-KO | $291.09 |
12-1/4" x 4" Electric Brake Assemblies
with 7 Bolt Cast Backing Plate for Dexter Axles
These are replacement brake assemblies for Dexter 10K trailer axles with 12.25" x 4.0" electric brakes. These brake assemblies have the cast backing plate with 7 mounting holes and auto adjusting brakes.
| Part Number |
Notes | Price | ||
|---|---|---|---|---|
 |
23438 | 12-1/4" x 4" 10K HD FSA LH Electric Brake Assy with 7 Bolt Backing Plate for Dexter Axles | $174.95 | |
 |
23439 | 12-1/4" x 4" 10K HD FSA RH Electric Brake Assy with 7 Bolt Backing Plate for Dexter Axles | $174.95 |
12-1/4" x 5" Electric Brake Assemblies
with 7 Bolt Cast Backing Plate for Dexter Axles
These are replacement brake assemblies for Dexter 15K trailer axles with 12.25" x 5.0" electric brakes. These brake assemblies have the cast backing plate with 7 mounting holes and auto adjusting brakes.
| Part Number |
Notes | Price | ||
|---|---|---|---|---|
 |
23446 | 12-1/4" x 5" 15K FSA LH Electric Brake Assy with 7 Bolt Cast Backing Plate for Dexter Axles | $182.61 | |
 |
23447 | 12-1/4" x 5" 15K FSA RH Electric Brake Assy with 7 Bolt Cast Backing Plate for Dexter Axles | $182.61 |
